Description
Product Part Number
EPH-GW04
Product Overview
The GW04 Dual Band Gateway enables seamless connection between EPH compatible wireless heating systems and the EMBER App, providing convenient remote access and control via smartphone or tablet.
Acting as an RF/WiFi interface, the GW04 communicates with EPH RF heating controls using radio frequency technology, while simultaneously connecting to the EMBER Cloud Server through the home’s WiFi network. Supporting both 2.4GHz and 5GHz wireless networks, it offers flexible and reliable connectivity for modern home environments.
Designed for straightforward installation, the gateway can be wall mounted or used as a free-standing unit, and includes a light indicator for clear operational status.
Technical Specification
- Product Name: GW04 – Dual Band Gateway
- Type: RF / WiFi Interface
- Application: Connects EPH RF heating systems to EMBER App
- WiFi Compatibility: 2.4GHz and 5GHz networks
- Mounting Options: Wall mounted or free standing
- Light Indicator: Yes
- Certifications: CE, UKCA
Electrical & Connectivity Specifications
| Model | Type | Power Supply | WiFi Connection | Mounting Type |
|---|---|---|---|---|
| GW04 | RF / WiFi Interface | 230Vac ±10% | 2.4GHz / 5GHz | Wall or Free Standing |
RF & Environmental Specifications
- RF Range: Max. 10m
- Ambient Operating Temperature: 0°C to 50°C
